In-Line 4 175hp

In-Line 4 175hp

  • Type

    In-Line 4

  • Disp.

    2.8L

  • Weight*

    483 lbs (20" Shaft)

  • Power

    175hp
I'm Interested In this Outboard

In-Line 4 175hp Specs

Engine Type: In-Line 4

Displacement: 2.8L

Bore x Stroke: 96 x 96mm (3.78 x 3.78 in)

Prop Shaft Horsepower: 175hp at 5500 RPM

Full Throttle RPM Range: 5000 - 6000 RPM

Alternator Output at W.O.T.: 50 Amp

Compression Ratio: 10.3:1

Fuel Induction System: EFI

Weight*: 219 kg (483 lbs) - 221 kg (487 lbs)

Recommended Fuel: Octane 87

Recommended Engine Oil: Yamalube® 4M (See owner's manual)

Recommended Fuel Filtration: Yamaha 10-Micron Fuel / Water Separating Filter (external)

Warranty: Limited 3-year Pleasure, 3-year Government, 1-Year Commercial

About the In-Line 4 175hp

The F175 is 30 pounds lighter than its closest 1.7-liter competitor, but it still delivers breathtaking acceleration, midrange punch and impressively smooth performance. It’s compatible with either mechanical controls or digital controls.

  • Available for digital (Command Link Plus®) or mechanical controls
  • Only 483 pounds (20” shaft model)
  • Available in 20” or 25” shafts
  • A 50-amp alternator to power an array of onboard electronics

* Weight refers to shortest shaft length, and is measured without motor oil, gearcase oil and propeller (except models 25 hp and under, which include a standard propeller).
