HB-LX Series
-
Length
7'10" - 11'6" -
Type
Rigid Hull -
Beam
5' - 5'9" -
Capacity
3 - 6 -
Weight
86 - 161 lbs -
Max HP
5 - 20 hp
About the HB-LX Series
A lightweight rigid hull series packed with high performance features.
The Achilles HB-LX boats provide the critically acclaimed performance of the Achilles DX deep "V" fiberglass hull design in a lighter RIB. They also have the same tube design as the DX series, yet a modification of the deck design and removing the bow locker results in a RIB that is on average 20% lighter than the same size DX model.
This means they can perform well with smaller engines and can be carried or transported more easily. Despite their lighter weight and lower cost compared to the HB-DX series, they are still loaded with all the high quality standard features for which Achilles is known.
Features
HB-LX Standard Features include:
- Pearl Gray Achilles CSM reinforced fabric
- Four-layer seam construction
- Deep "V" Fiberglass
- Full-length teardrop rubbing strake
- Removable wood rowing seat
- D-rings for towing bridle
- Stainless bow eye
- Lifting hardware for davits
- Webbed passenger, helmsman, and rear carry handles
- Bow carry handle
- Interior oar straps (except HB240-LX)
- Fold-down locking oar system with two-piece breakdown aluminum oars and oar holders
- Gas tank tie down hardware
- Protective transom motor clamp plate
- Extra seat attachment patches (except HB240-LX)
- Bailer valve
- Foot pump
- Maintenance kit
Hull Color Options
-
Classic Grady-White
Gelcoat
Standard Color
-
Celestial Blue
Gelcoat
Optional Color
-
Coastal Fog Blue
Gelcoat
Optional Color
-
Sand
Gelcoat
Optional Color
-
Sea Glass
Gelcoat
Optional Color
-
Seaport Blue
Gelcoat
Optional Color
-
Cape Gray
Paint
Optional Color
-
Harbor Blue
Paint
Optional Color
Hull Color Options
-
Custom White
Gelcoat
Standard Color
-
Gunmetal Gray
Gelcoat
Optional Color
-
Sandy Tan
Gelcoat
Optional Color
-
Horizon Blue
Gelcoat
Optional Color
-
Ice Blue
Gelcoat
Optional Color
-
Abaco Green
Gelcoat
Optional Color
Models
Length | Inside Length | Beam | Inside Beam | Tube Dia. | Weight | Load Capacity | Person Capacity | Recommend HP | Max HP | Air Chambers | Color | |
HB-240LX | 7'10" | 5'8" | 5' | 2'5" | 16" | 86 lbs | 900 lbs | 3 | 5 | 5 | 2 | Pearl Gray |
HB-280LX | 9'2" | 6'7" | 5'5" | 2'7" | 17" | 118 lbs | 1,210 lbs | 4 | 8 | 10 | 3 | Pearl Gray |
HB-315LX | 10'4" | 7'9" | 5'5" | 2'7" | 17" | 128 lbs | 1,320 lbs | 5 | 10 | 15 | 3 | Pearl Gray |
HB-350LX | 11'6" | 8'8" | 5'9" | 2'9" | 18" | 161 lbs | 1,680 lbs | 6 | 15 | 20 | 3 | Pearl Gray |
Length | Inside Length | Beam | Inside Beam | Tube Dia. | Weight | Load Capacity | Person Capacity | Recommend HP | Max HP | Air Chambers | Color | |
HB-240LX | 7'10" | 5'8" | 5' | 2'5" | 16" | 86 lbs | 900 lbs | 3 | 5 | 5 | 2 | Pearl Gray |
HB-280LX | 9'2" | 6'7" | 5'5" | 2'7" | 17" | 118 lbs | 1,210 lbs | 4 | 8 | 10 | 3 | Pearl Gray |
HB-315LX | 10'4" | 7'9" | 5'5" | 2'7" | 17" | 128 lbs | 1,320 lbs | 5 | 10 | 15 | 3 | Pearl Gray |
HB-350LX | 11'6" | 8'8" | 5'9" | 2'9" | 18" | 161 lbs | 1,680 lbs | 6 | 15 | 20 | 3 | Pearl Gray |
We have one in stock!
We have a HB-LX Series in stock now in our showroom.
Achilles HB-350LX
-
Length
11' 6" -
Type
Rigid Hull -
Capacity
6 -
Color
Pearl Gray
