HB-AL Series
-
Length
7'10" - 10'2" -
Type
Rigid Hull -
Beam
5'2" -
Capacity
3 - 4 -
Weight
88 - 112 lbs -
Max HP
6 - 15 hp
About the HB-AL Series
The Achilles aluminum hull ribs let you go anywhere.
Achilles incorporated all the best features of their pacesetting HB fiberglass hull inflatable boats into the HB-AL series. These rugged boats feature a marine grade aluminum hull that is powder-coated to ensure a smooth, long lasting finish. They offer the advantage of being lightweight yet remark- ably strong and durable. A modified V hull, combined with their lightweight, allow HB-AL boats to cut through water efficiently with less horsepower.
All three HB-AL boats are single hull models that keep the weight of the boats down. They also all have non-skid deck patches for better traction, safety and comfort. All of this is in addition to a host of other great features perfected by Achilles through their years as a leader in RIB design and inflatable boat technology. The HB-AL boats are a great choice for boaters who want a fuel-efficient and well-performing RIB that can handle rocky coastlines, coral, frequent beaching, and anything else you can throw at them.
Features
HB-AL Standard Features include:
- Achilles CSM reinforced fabric
- Four layer seam construction
- Powder-coated aluminum hull with non-skid patches (HB-310AL has full deck liner)
- Hull keel guard
- Fold-down locking oar system with two-piece breakdown aluminum oars and oar holders
- Interior oar straps (HB-310AL only)
- Full-length teardrop rubbing strake
- Towing bridle D-rings
- Welded bow eye
- Inside bow davit lifting eye
- Stern mounted davit lifting eyes
- Outside transom towing eyes
- Protective transom motor clamp plate
- Bow and stern carry handles
- Webbed passenger handles and helmsman handles
- Removable Aluminum rowing seat (gray painted)
- Extra seat attachment patches (except the HB-240AL)
- Bailer valve
- Foot pump
- Maintenance kit
Hull Color Options
-
Classic Grady-White
Gelcoat
Standard Color
-
Celestial Blue
Gelcoat
Optional Color
-
Coastal Fog Blue
Gelcoat
Optional Color
-
Sand
Gelcoat
Optional Color
-
Sea Glass
Gelcoat
Optional Color
-
Seaport Blue
Gelcoat
Optional Color
-
Cape Gray
Paint
Optional Color
-
Harbor Blue
Paint
Optional Color
Hull Color Options
-
Custom White
Gelcoat
Standard Color
-
Gunmetal Gray
Gelcoat
Optional Color
-
Sandy Tan
Gelcoat
Optional Color
-
Horizon Blue
Gelcoat
Optional Color
-
Ice Blue
Gelcoat
Optional Color
-
Abaco Green
Gelcoat
Optional Color
Models
Length | Inside Length | Beam | Inside Beam | Tube Dia. | Weight | Load Capacity | Person Capacity | Recommend HP | Max HP | Air Chambers | Color | |
HB-240AL | 7'10" | 5'3" | 5'2" | 2'4" | 17" | 88 lbs | 880 lbs | 3 | 6 | 6 | 3 | Pearl Gray |
HB-270AL | 8'10" | 6'3" | 5'2" | 2'4" | 17" | 98 lbs | 990 lbs | 4 | 8 | 8 | 3 | Pearl Gray |
HB-310AL | 10'2" | 7'3" | 5'2" | 2'4" | 17" | 112 lbs | 1,190 lbs | 4 | 10 | 15 | 3 | Pearl Gray |
Length | Inside Length | Beam | Inside Beam | Tube Dia. | Weight | Load Capacity | Person Capacity | Recommend HP | Max HP | Air Chambers | Color | |
HB-240AL | 7'10" | 5'3" | 5'2" | 2'4" | 17" | 88 lbs | 880 lbs | 3 | 6 | 6 | 3 | Pearl Gray |
HB-270AL | 8'10" | 6'3" | 5'2" | 2'4" | 17" | 98 lbs | 990 lbs | 4 | 8 | 8 | 3 | Pearl Gray |
HB-310AL | 10'2" | 7'3" | 5'2" | 2'4" | 17" | 112 lbs | 1,190 lbs | 4 | 10 | 15 | 3 | Pearl Gray |
We have one in stock!
We have a HB-AL Series in stock now in our showroom.
Achilles HB-310AL PG
-
Length
10' 2" -
Type
Rigid Hull -
Capacity
4 -
Color
Pearl Gray
